| LED Type | 2835 SMD |
| LED Quantity (leds/m) | 180 leds/m |
| Typical Color Temperature | 1900K/2700K/3000K/4000K/6000K |
| Work Voltage | 12V / 24V |
| Power | 20 w/m |
| Ra | 92+ |
| Cutting Unit | 3 LEDs 33.3mm(12V) 6 LEDs 66.6mm(24V) |
| PCB Width | 10mm |
| IP Rating Opthional | IP20/IP65/IP67/IP68 |
| Adhesive Tape | 3M 9495LE 300MP |
| Model No. | Specification | |||||||||
| LED Type | LED Qty (pcs/m) | Color | Color Temperature | Work Voltage | Power | Brightness | Ra | Cutting Unit | PCB Size | |
| A2835-180-60K-V24-NWP | SMD 2835 |
180 | White | 6000K±300K | 12V DC 24V DC |
20W/M | 1800～1920Lm | 92+ | 3 LEDs 33.3mm 6 LEDs 66.6mm |
5000*10mm 2 OZ(2550) |
| A2835-180-40K-V24-NWP | Natural White | 4000K±200K | ||||||||
| A2835-180-30K-V24-NWP | Warm White | 3000K±100K | ||||||||
| A2835-180-27K-V24-NWP | Warm White | 2700K±100K | ||||||||
| A2835-180-19K-V24-NWP | Golden Yellow | 1900K±100K | / | |||||||
| Package 1: 500m per carton |
|
Inner box: 25rolls 125m
34x20x22 cm / 3.7kg Outer Box : 4 inner boxes 500m 42x35x46cm / 15.5kg |
